This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
| Model | SMP-8048-110 / SMP-8048-110P | SMP-11048-110 / SMP-11048-110P | SMP-12048-120 / SMP-12048-120P |
|---|---|---|---|
| AC Input | |||
| Rated Input Voltage (Vac) | 230Vac±5% | ||
| Voltage Range (Vac) | (170Vac~280Vac)±2% (90Vac-280Vac)±2% | ||
| Frequency (Hz) | 50/60(Auto Adaptive) | ||
| AC Output | |||
| Rated Capacity (Kw) | 8000 | 11000 | 12000 |
| Surge Power (Kva) | 8000 | 11000 | 12000 |
| Voltage (Vac) | 230Vac | ||
| Power Factor (PF) | 1 | ||
| Frequency | 50/60Hz±0.1% | ||
| Switch Time (ms) | 10 (normal mode) / 10 (UPS mode) | ||
| Wave Form | Pure Sine Wave | ||
| Overload protection |
(102% < load <125%) ±10%: report error and turn off the output after 5 minutes; (125% < load < 150%) ± 10%: report error and turn off the output after 10 seconds; Load >150% ±10%: report error and turn off the output after 5 seconds; |
||
| Max. Efficiency | >93% | ||
| Parallel Quantity | NO / 1~6 | ||
| Bypass circuit breaker specification | 63A | ||
| Battery Specification | |||
| Rated battery input voltage | 48V (Minimum starting voltage 44V) | ||
| Battery voltage range | 40.0Vdc~60Vdc±0.6Vdc (Undervoltage alarm/shutdown voltage/overvoltage alarm/overvoltage recovery... settable on LCD screen) | ||
| Power saving mode self-consumption | Load≤50W | ||
| Solar Charger | |||
| Solar Charger Type | MPPT*2 | ||
| PV operating voltage range | 120-500Vdc | ||
| MPPT voltage range | 90-450Vdc | ||
| Max PV Voltage | 500Vdc | ||
| Maximum PV input power | 5500W+5500W | 6000W+6000W | |
| Maximum PV input current | 22A+22A | ||
| PV charging current range (can be set) | 0-150A | ||
| Charging short circuit protection | Blown fuse | ||
| Wiring protection | Reverse polarity protection | ||
| AC Charger | |||
| Max charger current (can be set) | 0-150A | ||
| Battery Type | Lithium and Lead-acid | ||
| Maximum charge current (can be set) | 120A | 150A | |
| Charge current error | ±5Adc | ||
| Charge voltage range | 40 – 60Vdc | ||
| Short circuit protection | Circuit breaker and blown fuse | ||
| Circuit breaker specifications | 63A | ||
| Environmental & Communication | |||
| Operating temperature range | -10°C to 55°C, > 45°C drop runs | ||
| Storage temperature range | -25°C ~ 55°C | ||
| Humidity range | 5% to 95% (Conformal coating protection) | ||
| Noise | ≤60dB | ||
| Heat dissipation | Forced air cooling, variable speed of fan | ||
| Communication interface | USB/RS485 (/WiFi/GPRS) / Dry node control | ||
